Sesotec Live Fachpack Powtech 2022

The new
RAYCON D+ HX

The high-end model for packaged products.
Live at the FACHPACK/POWTECH

Contaminant detection on a new level.

Our highlights at the
FACHPACK/POWTECH 2022.


Learn more


Experience live.

Arrange an appointment with us at the
FACHPACK/POWTECH 2022.

Make an appointment now


FACHPACK/POWTECH 2022
Nürnberg, 27.-29.09.2022
Hall 2, Stand 2-213

This year, two trade fairs are combining - FACHPACK and POWTECH. The result: a strong presentation platform for innovations around packaging, powder and bulk solids technology.

Sesotec presents the new RAYCON X-ray systems as well as metal detectors for piece and bulk goods. Come by and let our experts advise you on all aspects of food safety and contaminant detection.


Make an appointment now

Our highlights at
FACHPACK/POWTECH 2022


The RAYCON D+ HX LW Hygienic is our curtain-free high-end model specially designed for inspecting unpackaged products such as fresh, chilled or frozen meat products.

  • Has a 0.4 mm detector with a detection accuracy from 0.3 mm
  • Thanks to high belt speeds up to 300 products per minute can be inspected in real time
  • The RAYCON D+ HX LW Hygienic has an X-ray source with 200 W (40 - 60 KV / 3,3 - 5,0 mA)



RAYCON EX 1 is a solution that offers maximum performance and ease of use at a moderate price. For all food manufacturers and processors who value a balanced relationship between price, performance and quality.

  • Has a 0.8 mm detector with a detection accuracy from 0.6 mm
  • Thanks to high belt speeds of up to 1.4 m/sec. up to 900 products per minute can be inspected in real time
  • The RAYCON EX1 has an X-ray source with 60 W (40 - 50 KV / 1,25 - 1,5 mA)



VARICON+ D INTUITY

The INTUITY metal detector with THiNK technology based on artificial intelligence is one of the most innovative metal detectors on the market. Especially in difficult applications, such as meat products, which have a high intrinsic conductivity, conventional metal detectors reach their limits. INTUITY THiNK makes it possible to almost completely suppress the product effect and thus achieve extremely high sensitivities even in these applications. At the same time, false triggering is avoided, thus minimising food waste.

VARICON+ GLS MF

The conveyor belt solution VARICON+ GLS MF works with multi-frequency technology and is the standard model for inspecting piece goods and bulk goods on a conveyor belt with very good detection accuracy. Sesotec will be presenting the GLS MF tunnel metal detector with a 7-inch display together with the new Insight.HMI software. The associated advantages: Permanent machine and product overview, extended links for daily use, configurable dashboards according to the user role and increased ease of use (optimized operator guidance and control of devices via mobile device, particularly advantageous if a device is difficult to access).





The RAPID 5000 metal separator is used to inspect bulk materials in free-fall conveying lines. It detects all magnetic and non-magnetic metal contaminants (steel, stainless steel, aluminium, ...) - even if they are enclosed in the product. It helps food companies ensure the purity of free-falling bulk materials such as herbs, tea, spices, chemical additives, flour and sugar.



Our GF 4000 was specially developed for use in horizontal as well as vertical pneumatic conveying systems with high hygienic requirements. It reliably detects and separates magnetic and non-magnetic metal contaminants from bulk materials, powders and granulates. This precise inspection ensures conformity with all important food regulations.

The GF 4000 is equipped with automatic function test monitoring. Automatic feeding of the test pieces significantly shortens the test window and thus your downtimes and increases productivity.


Our metal detection systems for liquid and pasty products can be quickly and easily integrated into existing piping systems and connected to all common vacuum fillers, pumps, clipper systems and sausage meat filling systems. Thanks to various selectable separation systems, they guarantee safe and efficient rejection of all metallic contaminants.




Make an appointment now and secure an admission voucher.


Do you have a specific challenge that needs to be solved or would you like to talk to us about food safety in general? Then make a personal appointment with our experts directly at the Sesotec stand now.

Of course, if you make an appointment, you will also receive a free admission voucher from us.
